High Physical Security
Holding force 1,000kg - automatic deadlocking
Bolt throw 16mm
All stainless steel bolt of 12.7mm diameter,
linkages and springs. 3mm stainless steel faceplate and strike plates with fully enclosed mechanism.
Designed to provide concealed high security locking on any single or double action, hinged or sliding door in timber or metal for vertical or horizontal mounting.
210mm(L) x 25mm(W) x 42mm(D)
Back box 164mm(L) x 22mm(W) x 39mm(D)
Multiple Voltage Input
Any voltage from 12v DC -10% to 24v DC +15%. Complete with built in transient and reverse polarity protection and continuously rated solenoid.
Low Current Consumption
Volts Current - Activate Current - Hold (after 200ms)
12vDC 1100mA 210mA
24vDC 1000mA 90mA
Bolt and Door position switches
Built-in Access Control Module
Automatic unlock period - 9 seconds
Multiple auto relock function - PTL
Multiple unlock function - PTO
Stainless steel surface mount kit
