Technology: |
active infrared with background suppression |
|
---|---|---|
Emission field: |
400 mm (W) x 70 mm (D) (at 2 m mounting height; 4 spots active) |
|
Mounting height: |
1.3 m to 3.5 m* |
|
Reaction time: |
64 ms (typ) |
|
Max. presence time: |
infinite |
|
Supply voltage: |
12 V - 24 V AC +/-10% ; 12 V - 30 V DC -5%/+10% (to be operated from SELV compatible power supplies only) |
|
Max current consumption: |
95 mA @ 24 V AC/ 70 mA @ 24 V DC; 170 mA @ 12 V AC/ 130 mA @ 12 V DC (MASTER) |
|
Output: |
2 relays (free of potential contact) |
|
Input: |
1 optocoupler (free of potential contact) |
|
Max. number of modules: |
4 (up to 6 if 24 V DC) |
|
Reflectivity: |
min. 5% at IR-wavelength of 850 nm |
|
Degree of protection: |
IP53 |
|
Temperature range: |
-25 °C to +55 °C; 0-95% relative humidity, non condensing |
|
Expected lifetime: |
20 years |
|
Norm conformity: |
This product conforms to all applicable European Union legislation. Please refer to the Declaration of Conformity for further information. |
Specifications are subject to changes without prior notice – Measured in specific conditions.
* max. mounting height for BS 7036-conformity (UK): 3.25 m
