BEA 4SAFE 700mm

active infrared with background suppression

400 mm (W) x 70 mm (D) (at 2 m mounting height; 4 spots active)

1.3 m to 3.5 m*

64 ms (typ)

infinite

12 V - 24 V AC +/-10% ; 12 V - 30 V DC -5%/+10% (to be operated from SELV compatible power supplies only)

95 mA @ 24 V AC/ 70 mA @ 24 V DC; 170 mA @ 12 V AC/ 130 mA @ 12 V DC (MASTER)
85 mA @ 24 V AC/ 60 mA @ 24 V DC; 180 mA @ 12 V AC/ 113 mA @ 12 V DC (other modules)

2 relays (free of potential contact)
42 V AC/DC
1 A (resistive)
30 W (DC) / 42 VA (AC)

1 optocoupler (free of potential contact)
30 V
high: >10 V DC; low: <1 V DC

4 (up to 6 if 24 V DC)

min. 5% at IR-wavelength of 850 nm

IP53

-25 °C to +55 °C; 0-95% relative humidity, non condensing

20 years

This product conforms to all applicable European Union legislation. Please refer to the Declaration of Conformity for further information.
